WS

Water Cooled

WS350
Compliant (EN60974-7)
Cycles at 100% CO2: 330 A
Cycles at 100% MIX (M21): 300 A
Wires diameter: Ø 0,8-1,2 mm
Pressione ingresso torcia: Min 2.5 Bar / Max 3.5 Bar
Flusso liquido minimo: 1.3 Lt./min

WS500
Compliant (EN60974-7)
Cycles at CO2: 500 A
Cycles at MIX (M21): 450 A
Wires diameter: Ø 0,8-1,6 mm
Torch inlet pressure: Min 2.5 Bar / Max 3.5 Bar
Minimum liquid flow: 2.0 Lt./min

Main features
  • Ergonomic handle of reduced size for an optimal balance.
  • Gas diffusers and nozzle holders with external metal protection, for increased durability and heat resistance.
  • Spherical joint on the handle with optimal range of motion.
  • Thread guide tips with increased pitch to reduce the problems of binding, in high quality copper alloys, with a length of 40 mm to optimize the current transmission between wire and tip.
  • External nozzles with increased length combined with an insulator of the highest quality to allow considerable disposal of the heat.
  • High performance fl exible coaxial cable.
  • Push button complete with reed switch unique of its kind high performance.
  • Liquid cooling circuit with increased fl ow rate thanks to the torch body and to the current cable connections.
  • Cooled current cables with tinned copper braid for one greater durability and resistance to oxidation. Copper fittings for a greater transmission of current.
  • Sturdy torch bodies designed to improve circulation of the liquid and heat dissipation.
  • Long-lasting soft rubber water passage hoses.
  • Wiring, connections and assemblies complete the features high level.
